The High Current Probe HCF76289B310100620G300 (item number 1023602) is designed for electrical test and contacting tasks with elevated current loads. HCF76289B310100620G300 focuses on current capacity and low transition losses, as required in battery testing, formation and other e-mobility applications. For HCF76289B310100620G300, current capacity, low contact resistance and defined contact force are key to limiting electrical losses and unwanted heating. The design combines a pitch of 4 mm / 157 mil with tip style 89 (Special version of spade tips) and a tip diameter of 3.1 mm. HCF76289B310100620G300 operates with 300 cN spring force and 4 mm nominal travel. The continuous-current rating of HCF76289B310100620G300 is 40 A.
