The High Current Probe HCF34806B600G1400A (item number 1089311) is designed for safe transmission of high electrical currents in test and contacting applications. HCF34806B600G1400A focuses on current capacity and low transition losses, as required in battery testing, formation and other e-mobility applications. For HCF34806B600G1400A, contact resistance, contact force and thermal behavior must be considered together because they influence voltage drop and temperature rise at the contact point. The intended application area for HCF34806B600G1400A includes battery and power-electronics testing. HCF34806B600G1400A is rated for 100 A continuous current with a typical contact resistance of 5 mΩ. HCF34806B600G1400A operates with 1400 cN spring force and 4.4 mm nominal travel.
