The High Current Probe HCF77206B200G300A (item number 1165641) is designed for safe transmission of high electrical currents in test and contacting applications. HCF77206B200G300A focuses on current capacity and low transition losses, as required in battery testing, formation and other e-mobility applications. For HCF77206B200G300A, contact resistance, contact force and thermal behavior must be considered together because they influence voltage drop and temperature rise at the contact point. The intended application area for HCF77206B200G300A includes battery and power-electronics testing. The electrical rating of HCF77206B200G300A combines 20 A continuous current with 10 mΩ typical contact resistance. HCF77206B200G300A operates with 300 cN spring force and 4 mm nominal travel.
