The High Current Block HCB166B12ALS80 (item number 1145585) is designed for test and contacting tasks with high electrical currents. HCB166B12ALS80 focuses on current capacity and low transition losses, as required in battery testing, formation and other e-mobility applications. In HCB166B12ALS80, the compact assembly integrates the current path into a defined interface, where current capability, contact resistance and contact force are key design parameters. This version is intended for contacting Inverter. Spring force is 8000 cN at a nominal travel of 4.4 mm.
