As a Basic Contact Probe, F56307S300P300 (item number 1095541) establishes a spring-loaded electrical connection to the test point. With tip style 07 (Hexagonal 90° stepped), F56307S300P300 combines ICT/FCT use with a geometry intended for plated vias and pads where sharp edges penetrate contamination and oxide layers. The design combines a pitch of 3 mm / 118 mil with tip style 07 (Hexagonal 90° stepped) and a tip diameter of 3 mm. F56307S300P300 operates with 300 cN spring force and 4.3 mm nominal travel. The electrical rating of F56307S300P300 combines 6 A continuous current with 100 mΩ typical contact resistance. The plunger in F56307S300P300 is made of steel and uses Progressive Coating.
