The Basic Contact Probe F10035S150P300HP (item number 1036217) is a spring-loaded probe for temporary electrical contact with test points. With tip style 35 (3-point crown stepped (self-cleaning)), F10035S150P300HP combines ICT/FCT use with a geometry intended for solder pads and vias. F10035S150P300HP combines a pitch of 2.54 mm / 100 mil with tip style 35 (3-point crown stepped (self-cleaning)) and a tip diameter of 1.5 mm. For F10035S150P300HP, spring force is 300 cN at a nominal travel of 4.3 mm. The electrical rating of F10035S150P300HP combines 5 A continuous current with 20 mΩ typical contact resistance. Two features address difficult surface conditions on F10035S150P300HP: Progressive Coating reduces contamination sensitivity, while the HP spring provides increased preload at the start of the contact stroke.
