Technical data
| General | |
|---|---|
| Type/family | IB |
| Temperature | -45°C...+100°C |
| Additional definition | FL |
| Dimensions | |
|---|---|
| Total length (mm) | 60 |
| Protrusion height (mm) | 3.9 |
| Tip style diameter (mm) | 1.05 |
| Materials and surfaces | |
|---|---|
| Tip style | 3 |
| Tip style material | Beryllium copper |
| Tip style plating | Gold |
| Plunger material | Beryllium copper |
| Plunger plating | Gold |
| Block material | HGW FR4 |
| Block plating | Uncoated |
| Spring material | Spring steel |
| Spring plating | Silver |
| Mechanical specifications | |
|---|---|
| Preload (cN) | 60 |
| Spring force (cN) | 110 |
| Nominal travel (mm) | 2.6 |
| Maximum travel (mm) | 3.2 |
| Electrical specifications | |
|---|---|
| Continuous current (A) | 4 |
