Technical data
| Specifications | |
|---|---|
| Min. pitch of the test item | 50 µm |
| Minimum diameter of the contact element | 1,6 mil |
| Max. contact area | 105 mm x 105 mm |
| Temperature | -55°C...+180°C |
| Current carrying capacity at room temperature | 800 mA |
| Contact force at recommended delivery | 2,4 cN - 10,8 cN |
| Contact materials | |
|---|---|
| Contact material 1 | Gold |
| Contact material 2 | Palladium |
| Contact material 3 | Diverse |
| Contact material 4 | Solder ball |
| Contact material 5 | Aluminium |
| Contact material 6 | Copper |
